MikroTik CCR10097G1C1S+ Cloud Core Router
1U Rackmount
$650.00
The MikroTik CCR10097G1C1S+ is a highperformance, professionalgrade cloud core router designed to deliver exceptional routing capacity, flexibility, and reliability for demanding network environments. Part of MikroTik’s Cloud Core Router (CCR) series, it combines a powerful multicore CPU, advanced port configuration, and robust software features — making it an ideal choice for ISPs, enterprise networks, and highcapacity deployments where uptime and performance are critical.
Key Features:
High Performance Processing: Powered by a Tilera 9core 1.2 GHz CPU with hardware acceleration, the CCR1009 handles intensive routing tasks, complex firewall rules, and highvolume traffic without compromising throughput. With 2 GB of DDR3 RAM and a highspeed NAND storage system, it ensures smooth operation under heavy loads.
Versatile Connectivity: Equipped with 7 Gigabit Ethernet ports, 1 combo Gigabit Ethernet/SFP port, and 1 SFP+ 10G port, this router provides flexible WAN/LAN configurations suitable for fiber or copper networking. The combo port allows seamless use of either SFP or RJ45, maximizing deployment options.
EnterpriseGrade Routing Features: Supports advanced Layer 3 routing protocols, VLANs, MPLS, BGP, OSPF, and policybased routing. Ideal for complex, segmented networks requiring highperformance routing and redundancy.
Redundant Power Options: Features an integrated AC power supply and PoE input support for redundancy, ensuring uninterrupted operation even during power feed changes or failures.
Fanless Passive Cooling: Designed with a completely passive cooling system — the CCR1009 operates silently and is less susceptible to dust and mechanical failure, making it reliable for longterm datacenter or office deployment.
RouterOS Power: Runs on MikroTik RouterOS, offering a full suite of enterprise networking capabilities — including advanced firewall, DPI (Deep Packet Inspection), QoS, hotspot, IPsec, tunneling, and monitoring — all managed through a powerful webbased GUI, CLI, or WinBox interface.
Specifications:
Form Factor: 1U rackmount
CPU: Tilera TileGX9, 9 cores, 1.2 GHz
RAM: 2 GB DDR3
Storage: 128 MB NAND
Ports:
7 × 10/100/1000 Gigabit Ethernet
1 × Combo Gigabit Ethernet/SFP port
1 × SFP+ 10G port
Power Input: 1 × AC input, PoEin (Passive PoE, 18–57 V) on combo port
Cooling: Fanless passive cooling system
Operating System: MikroTik RouterOS (Level 6 license)
Dimensions: 443 × 183 × 44 mm
Weight: ~1.74 kg (3.84 lbs)
Max Power Consumption: ~25 W
Ideal For:
Internet Service Providers (ISPs) managing highcapacity backbone routes
Enterprise core or edge routing with multiple WAN links
Data centers requiring highperformance Layer 3 routing and redundancy
Networks migrating to 10G connectivity
Environments prioritizing silent, fanless, and reliable hardware
